Probes Set, Hand Held | EM-6992

The EM-6992 Probe Kit includes five probes (three (3) Magnetic Field probes and two (2) Electric Field Probes) as well as a 20cm extension handle for accessing hard-to-reach places. The probes are designed for the detection of E-Field and H-Field emissions and are suited for EMC/Pre-Compliance testing as well as performing basic electric and magnetic field measurements.

Add to Quote
Categories: , , ,

Electrical

Frequency Range: DC to >1000MHz

Connector: BNC (female)

Model:

EM-6993:

  • 6cm Loop H-Field Probe
  • H-Field Probe
  • E-Field rejection: 41 dB
  • Resonant Frequency: 540 MHz

EM-6994:

  • 3cm Loop H-Field Probe
  • H-Field Probe
  • E-Field rejection: 29 dB
  • Resonant Frequency: 950 MHz

EM-6995:

  • 1cm Loop H-Field Probe
  • H-Field Probe
  • E-Field rejection: 11 dB
  • Resonant Frequency: 2500 MHz

EM-6996:

  • 3.6cm Ball E-Field Probe
  • E-Field Probe
  • H-Field rejection: 30 dB
  • Resonant Frequency: > 1000 MHz

EM-6997:

  • Stub E-Field Probe
  • E-Field Probe
  • H-Field rejection: 30 dB
  • Resonant Frequency: > 1500 MHz

Mechanical

Kit Dimensions:

  • Length: 33 cm (13”)
  • Width: 27.9 cm (11”)
  • Height: (5.5”)

Weight: 1.96 kg (4.32 lbs.)

Data Sheets

Download Data Sheet
