EM-6106 Battery Pack comprises a rectangular box containing a battery-powered, fused, regulated 15 VDC power supply with a rechargeable high capacity, military grade Li-ion battery, which can be charged by an external battery charger. The nominal operating time on a fully charged battery pack is 24 hours*.
Applications
EM-6105 Active Omni-Directional
Wideband Discone Antenna (10kHz –2GHz)
EM-6877 Active Loop Antenna (9kHz –30MHz)
Frequency Range: 10 kHz – 2GHz
Output VSWR: < 2:1 Typical
Output Voltage (Input Port): +15V Nominal
Impedance: 50Ω, Nominal
Connector: Type ‘N’ (f) Output
Type ‘N’ (m) Input (+15V DC to Instrument)
Battery: 24V, Lithium-Ion Cell Chemistry
Operating Time: 24 Hours, Nominal
Battery Operating Temperature: -32C, +60C
Charger: 12.6V @ 2.0A Output
100-240VAC, 47-63Hz Input
Dimensions
Width: 7.35 in. (187 mm)
Depth: 6.00 in. (152 mm)
Height: 2.88 in. (72 mm)
Weight: 5.42 lbs. (2.46 kg)
Mounting Options Available
¼-20 Top Antenna Mount
Accessories
Power Supply/Charger Module (Included)
Type N (f) – Type N (m) 6’ Input Cable
Color Options
Black (default)
